Ventair HEATFORCE - 2/4 DC Bathroom LED Downlight
Air movement specialists
HEATFORCE
Ceiling-mounted radiant heat and ducted extraction, with the light arrangement specified for the selected model.
Before you buy
- A licensed electrician must install the bathroom unit and fixed wiring. Plan the exact cut-out, installation depth and duct route before cutting.
- Keep the unit clear of insulation and follow its ceiling, wall and wet-area clearances. Provide replacement air into the room to support extraction.
- The thermal safety circuit needs the permanent active connection shown in the exact installation manual.
Highlights
Air Delivery
24/7: 75m³/h - Standard:285m³/hMotor Power
24/7: 2.5W - Standard: 25WLight Wattage
10WIP Rating
IPX4Key features
Heat and ventilation
Separate heat and exhaust functions provide warmth and extraction in one ceiling unit.
Extraction
24/7: 75m³/h - Standard:285m³/h. Provide replacement air into the room for effective ventilation.
Bathroom lighting
10W lighting; the exact light and heat-lamp arrangement is shown for each option.
Ducted exhaust
A side duct and backdraft stopper guide exhaust air towards the outside.
Easy access
The removable fascia allows routine cleaning after the power is isolated and the lamps have cooled.
Ventilation modes
Select continuous 24/7 trickle, a 10-minute run-on timer or standard extraction. The thermal safety switch protects the unit.
Technical specifications
HEA2W
- Globe Wattage (W)
- 10W
- Lumen Output
- 853Lm
- Colour Temperature
- 3000K / 4000K / 5000K
- Motor Type
- DC
- Ball bearing motor
- Yes
- Exhaust Motor Power
- 24/7: 2.5W - Standard: 25W
- Air Delivery
- 24/7: 75m³/h - Standard:285m³/h
- Speed (RPM)
- 24/7: 500RPM - Standard: 1450RPM
- Noise Level
- 24 /7: 28dB(A) - Standard: 42dB(A)
- Down Light
- 1 x 10W Tri-Colour LED
- LED Lumens
- 853(Avg)
- LED Tri-Colour Temperature
- WW: 3000K, NW: 4000K, CW: 5000K
- Heat Lamps
- 2 x 275w globes
- Mount
- Ceiling
- IP Rating
- IPX4
- Installation
- Qualified Electrician Required
- Power Input
- 220-240V~ 50Hz
- Model Number
- HEA2W
HEA4W
- Globe Wattage (W)
- 10W
- Lumen Output
- 853Lm
- Colour Temperature
- 3000K / 4000K / 5000K
- Motor Type
- DC
- Ball bearing motor
- Yes
- Exhaust Motor Power
- 24/7: 2.5W - Standard: 25W
- Air Delivery
- 24/7: 75m³/h - Standard:285m³/h
- Speed (RPM)
- 24/7: 500RPM - Standard: 1450RPM
- Noise Level
- 24 /7: 28dB(A) - Standard: 42dB(A)
- Down Light
- 1 x 10W Tri-Colour LED
- LED Lumens
- 853(Avg)
- LED Tri-Colour Temperature
- WW: 3000K, NW: 4000K, CW: 5000K
- Heat Lamps
- 4 x 275w globes
- Mount
- Ceiling
- IP Rating
- IPX4
- Installation
- Qualified Electrician Required
- Power Input
- 220-240V~ 50Hz
- Model Number
- HEA4W
Dimensions and installation space
HEA2W
- L
- 395mm x H: 395mm - 4 Lamps
- Side outlet duct size
- Ø150mm
- Cut out size
- 380 x 202mm
- Fascia Size
- 443mm x 268mm
- Min. install depth
- 220mm
HEA4W
- L
- 395mm x H: 395mm - 4 Lamps
- Side outlet duct size
- Ø150mm
- Cut out size
- 320 x 320mm
- Fascia Size
- 395mm x 395mm
- Min. install depth
- 220mm
What is included
- Bathroom unit, selected two- or four-lamp arrangement of 275W heat globes, 10W tri-colour LED light, wall switch plate, ducting and external grille.
Installation and care
- Keep ducting expanded and routes as straight as practicable. Exhaust outdoors using the outlet specified for the installation.
- Switch off and allow heat lamps to cool before cleaning or replacement. Clean the fascia with a soft cloth and keep the motor and electrical parts dry.
Warranty
HEA2W
- Warranty
- 5 years (2 years on spare parts, LED light and labour additional 3 years replacement only for fan and exhaust motors)
HEA4W
- Warranty
- 5 years (2 years on spare parts, LED light and labour additional 3 years replacement only for fan and exhaust motors)
