Domus PLEX Vivid 3 Metre 15W/m Green Outdoor Strip and Driver Bundle
PLEX-VIVID-IP67 · 3m bundle
LED strip with a choice of Domus driver
A fixed green dotless COB strip for a continuous line of colour.
Before you buy
- 3m of PLEX-VIVID-IP67 LED strip (DL-24142) and one Domus driver are included. Choose the driver option for this bundle; the exact driver is listed below.
- This bundle is for one continuous 3m run, powered from one end. The strip's verified maximum single-end run is 5m.
- Driver selection uses rated output at least 20% above the calculated strip load; this is the sizing allowance used for this bundle.
- Install the strip on an aluminium heat sink / profile. Domus states that omitting the heat sink voids the strip warranty.
- The strip is rated IP67. Maintain the manufacturer’s sealing and termination requirements at cut ends, cable entries and joins; the completed installation depends on every component.
- A compatible dimmer is required separately for a dimmable driver. Confirm the installed dimmer and load compatibility; minimum-load performance is not specified here.
- Mains electrical work must be carried out by a licensed electrician.
Key highlights
3m
Included strip length
45W
Calculated strip load
24V DC
Strip input voltage
Green
Light colour
Features
Fixed green colour
This exact strip SKU produces a single static green light colour.
Dotless COB light
640 LEDs per metre produce a continuous line of light.
Marked cut points
Cut at the marked 25mm increments.
One-end feed
The manufacturer permits a maximum 5m continuous run powered from one end.
Technical specifications
- Strip model
- PLEX-VIVID-IP67
- Source strip SKU
- DL-24142
- Included strip length
- 3m
- Strip power per metre
- 15W/m
- Calculated strip load
- 45W (15W/m × 3m)
- Strip input voltage
- 24V DC
- Maximum continuous single-end run
- 5m
- Light colour
- Green
- Strip IP rating
- IP67
- LED type
- COB
- Wiring
- Parallel
- Beam angle
- 180°
- LED density
- 640 LEDs/m
- Light output
- 1400lm/m — Green
- Strip dimming
- With suitable LED driver and control
- Operating temperature
- −20°C to 50°C
- Colour operation
- Single fixed green colour
Strip dimensions
- Strip width
- 12mm
- Strip height
- 4.5mm
- Cut interval
- 25mm
- End cap width
- 16.5mm
- End cap height
- 6.5mm
Driver options
Each option includes the driver shown in its row. Select one option for the 3m strip bundle.
| Driver option | Included driver | Rated output | Driver control | Driver IP |
|---|---|---|---|---|
| Indoor Non-dimmable | DRIVER-24V-IP20DL-20211 | 60W24V DC | Constant-voltage power supply; no mains dimming | IP20 |
| Indoor Dimmable | DRIVER-24V-IP20-DIMDL-20219 | 60W24V DC | Triac, suitable external dimmer required | IP20 |
| Outdoor Non-dimmable | DRIVER-24V-IP67DL-20226 | 60W24V DC | Constant-voltage power supply; no mains dimming | IP67 |
| Outdoor Dimmable | DRIVER-24V-IP67-DIMDL-20237 | 60W24V DC | Triac, suitable external dimmer required | IP67 |
Indoor Non-dimmable — DRIVER-24V-IP20 (DL-20211)
- Input voltage
- 240V AC
- Output type
- Constant voltage
- Protection
- Secondary-side short-circuit protection; Thermal overload protection; Over-temperature protection; Over-voltage protection
- Supplied cable
- 1m flex and plug
- Wiring
- Parallel wiring
- Indoor use only; install the IP20 driver in a dry location.
Indoor Dimmable — DRIVER-24V-IP20-DIM (DL-20219)
- Input voltage
- 240V AC
- Output type
- Constant voltage
- Protection
- Secondary-side short-circuit protection; Thermal overload protection; Over-temperature protection; Over-voltage protection
- Supplied cable
- 1m flex and plug
- Wiring
- Parallel wiring
- Driver dimensions (L × W × H)
- 133 × 46 × 29mm
- Indoor use only; install the IP20 driver in a dry location.
Outdoor Non-dimmable — DRIVER-24V-IP67 (DL-20226)
- Input voltage
- 240V AC
- Output type
- Constant voltage
- Protection
- Secondary-side short-circuit protection; Thermal overload protection; Over-temperature protection; Over-voltage protection
- Supplied cable
- 1m flex and plug
- Wiring
- Parallel wiring
- IP67 driver suitable for outdoor use. Protect mains connection and all cable joints to suit the installation; the driver IP rating does not transfer to the strip or other components.
Outdoor Dimmable — DRIVER-24V-IP67-DIM (DL-20237)
- Input voltage
- 240V AC
- Output type
- Constant voltage
- Protection
- Secondary-side short-circuit protection; Thermal overload protection; Over-temperature protection; Over-voltage protection
- Supplied cable
- 1m flex and plug
- Wiring
- Parallel wiring
- IP67 driver suitable for outdoor use. Protect mains connection and all cable joints to suit the installation; the driver IP rating does not transfer to the strip or other components.
What's included
- 3m of PLEX-VIVID-IP67 LED strip — source SKU DL-24142.
- 1 × Domus LED driver matched to the selected driver option above.
Required separately
- Suitable dimmer for a dimmable driver option.
- Suitable aluminium heat sink / mounting profile.
Not included
- Aluminium mounting profile/heat sink, installation labour and separately listed installation accessories.
Installation & maintenance
Recommended: mount the strip in a compatible heat-dissipating aluminium profile (sold separately). Follow Domus mounting instructions.
- Mains electrical work must be carried out by a licensed electrician.
- Supply the selected strip quantity as one continuous run. Feed the strip from one end only.
- Cut only at the marked 25mm cutting points.
- Install the strip on an aluminium heat sink / profile. Domus states that omitting the heat sink voids the strip warranty.
- Preserve the ingress protection at all field-cut ends and joints using the manufacturer’s termination method.
Warranty
- Indoor Non-dimmable (DL-20211): 5-year replacement warranty
- Indoor Dimmable (DL-20219): 5-year replacement warranty
- Outdoor Non-dimmable (DL-20226): 5-year replacement warranty
- Outdoor Dimmable (DL-20237): 5-year replacement warranty
