Domus PLEO 3 Metre 14.4W/m RGB Outdoor Strip and Driver Bundle
PLEO-14.4-S-RGB · 3m bundle
LED strip with a choice of Domus driver
Flexible side view neon LED strip for a continuous line of RGB colour light.
Before you buy
- 3m of PLEO-14.4-S-RGB LED strip (DL-20360) and one Domus driver are included. Choose the driver option for this bundle; the exact driver is listed below.
- Maximum single-end run is not published; the installer must confirm this 3m one-end-fed configuration with Domus before installation.
- Driver selection uses rated output at least 20% above the calculated strip load; this is the sizing allowance used for this bundle.
- A compatible RGB controller is required separately. Confirm the strip’s control protocol before choosing the controller; the LED driver alone does not provide colour control.
- The strip is rated IP67 only with correctly sealed terminations. An IP20 indoor driver must remain dry; an IP67 driver does not make unsealed cuts or joints weatherproof.
- A compatible RGB controller is required separately. A driver alone does not provide RGB control.
- Mains electrical work must be carried out by a licensed electrician.
Key highlights
3m
Included strip length
43.2W
Calculated strip load
24V DC
Strip input voltage
RGB
Light colour
Features
Side view light
Mount and bend the strip in its designed plane using compatible PLEO mounting accessories.
Marked cut points
Cut only at the marked 50mm intervals and seal every field cut, end and joint.
24V supply
A 24V DC constant-voltage driver supplies the 14.4W/m strip.
Technical specifications
- Strip model
- PLEO-14.4-S-RGB
- Source strip SKU
- DL-20360
- Included strip length
- 3m
- Strip power per metre
- 14.4W/m
- Calculated strip load
- 43.2W (14.4W/m × 3m)
- Strip input voltage
- 24V DC
- Light colour
- RGB
- Strip IP rating
- IP67
- LEDs per metre
- 140
- Light direction
- Side view
- Beam angle
- 115°
- Lumens per metre
- Red 111lm, green 348lm, blue 70lm
- LED type
- 2835 SMD (San'an)
- Wiring
- Parallel
- Operating temperature
- -15°C to 85°C
- Dimming
- Via suitable controller
- Input voltage
- 24V DC
- Power per metre
- 14.4W
- IP rating
- IP67
- Cutting interval
- 50mm
Strip dimensions
- Neon body cross-section
- 11 × 7.5mm
- Internal strip cross-section (diagram)
- 8 × 6.5mm
- End cap frontal dimension
- 12mm
- Lead length
- 150mm
- Cut interval
- 50mm — follow marked cut points
Driver options
Each option includes the driver shown in its row. Select one option for the 3m strip bundle.
| Driver option | Included driver | Rated output | Driver control | Driver IP |
|---|---|---|---|---|
| Indoor Non-dimmable | DRIVER-24V-IP20DL-20211 | 60W24V DC | Constant-voltage power supply; no mains dimming | IP20 |
| Outdoor Non-dimmable | DRIVER-24V-IP67DL-20226 | 60W24V DC | Constant-voltage power supply; no mains dimming | IP67 |
Indoor Non-dimmable — DRIVER-24V-IP20 (DL-20211)
- Input voltage
- 240V AC
- Output type
- Constant voltage
- Protection
- Secondary-side short-circuit protection; Thermal overload protection; Over-temperature protection; Over-voltage protection
- Supplied cable
- 1m flex and plug
- Wiring
- Parallel wiring
- Indoor use only; install the IP20 driver in a dry location.
Outdoor Non-dimmable — DRIVER-24V-IP67 (DL-20226)
- Input voltage
- 240V AC
- Output type
- Constant voltage
- Protection
- Secondary-side short-circuit protection; Thermal overload protection; Over-temperature protection; Over-voltage protection
- Supplied cable
- 1m flex and plug
- Wiring
- Parallel wiring
- IP67 driver suitable for outdoor use. Protect mains connection and all cable joints to suit the installation; the driver IP rating does not transfer to the strip or other components.
What's included
- 3m of PLEO-14.4-S-RGB LED strip — source SKU DL-20360.
- 1 × Domus LED driver matched to the selected driver option above.
- Manufacturer-supplied mounting clips.
Required separately
- Compatible RGB controller, selected after confirming the strip’s control protocol. No colour controller is included.
- Compatible RGB controller and its required control device.
Not included
- Additional mounting profile or extra clips, installation labour and separately listed installation accessories.
- RGB colour controller.
Installation & maintenance
Recommended: mount the strip in a compatible heat-dissipating aluminium profile (sold separately). Follow Domus mounting instructions.
- Mains electrical work must be carried out by a licensed electrician.
- Supply the selected strip quantity as one continuous run. Feed the strip from one end only.
- Cut only at marked 50mm intervals.
- Field cuts, ends and joints must be terminated and sealed to the manufacturer instructions.
- Use compatible PLEO mounting clips/profile and observe the designed bending plane.
Warranty
- LED strip: 3-year replacement warranty
- Indoor Non-dimmable (DL-20211): 5-year replacement warranty
- Outdoor Non-dimmable (DL-20226): 5-year replacement warranty
Product documentation
